For those off-road enthusiasts who crave exploring the wilderness, it's not a question of "if," but "when" you'll get stuck. That's where our BUNKER INDUST 6,000lbs electric winch can bail you out. When things get sticky, whether for you or your buddies, unleash its pulling power to save the day. Equipped with a 3.2HP permanent magnet motor, it's connected to a 3-stage planetary gear system boasting a 192:1 gear ratio. This configuration ensures enhanced pulling power and faster line speed. Our ATV winch/electric winch features an aluminium housing with UV-resistant finish. Its IP67 rating defies harsh outdoor conditions. Installation is a breeze with its bolt-on design, tailored for UTV/ATV. The automatic braking system will secure you on the steepest slopes. The remote controller also comes with integrated LED lights, which can double as a work light. Moreover, our clutch caps are available in yellow, orange, red, and black, enabling you to choose the colour that fits your rig.
Features
| Electric Winch: | |
|---|---|
| Housing: | Aluminium |
| Finish: | Matte Black Powder Coating |
| Hawse: | Aluminium |
| Hook: | Forged Steel |
| Waterproof: | IP-67 |
| Rated Line Pull(Single Line): | 6,000bs (2,722kg) |
| Motor: | 3.2HP (2.4kW); Permanent Magnet Motor |
| Gear Train: | Differential Planetary |
| Gear Reduction Ratio: | 192:1 |
| Gear Train: | 3-Stage Planetary |
| Free Spooling Clutch: | Turn |
| Drum Diameter/Length: | Ø50.08mm x 127.5mm |
| Brake: | Automatic Load-Holding Brake |
| Duty Cycle: | Intermittent Per SAE J706 Section 6.2 |
| Mounting Bolt Pattern: | 168mm x 74mm |
| Recommended Battery: | 175CCA |
| Control Mode: | Wired/Wireless Control |
| Full Load Line Speed (m/min): | 1.524m |
| No-Load Line Speed (m/min): | 4.2m |
| Max Current at Full Load (A): | 240 (amps) |
| Certification: | CE |
| Synthetic Rope: | |
| Material: | UHMWPE |
| Rope Length: | 15m |
| Breaking Capacity: | 7,716lbs (3,500kg) |
| Remote Controller: | |
| Operating Band: | 433MHz |
| Remote Control Distance: | 15m |
| Input Voltage: | 5V |
| Waterproof: | No |
| Package Size: | 50 x 30 x 17cm |
| Package Weight: | 14.7KG |
2 Year Warranty For Electric Components
3 Years Warranty For Mechanical Components
1 Year For Synthetic Rope
